Heavyweight Combination Plate Compactor PCX 12/36 & 13/40

DUE TO MANUFACTURER DELAYS AND INCREASED DEMAND THERE ARE LONG LEAD TIMES ON ALL BELLE PRODUCTS PLEASE CHECK BEFORE ORDERING

Heavyweight Combination Plate Compactors

Heavyweight professional compaction plates with low HAV and very high performance compaction. Designed with a shorter baseplate to offer improved compaction, manoeuvrability and finish.

• Foldable mounted guide handle offers superior manoeuvrability and can be lowered to operate under obstacles and close to form work.
• Reinforced centrifugal clutch ensures longer belt life, and simplified belt adjustment
• Lifting points and front lift cage offer easier loading and unloading for operator convenience
• Large capacity water tank is built into the protective frame
• Angled holes on spray bar allow complete water coverage over the full width preventing any asphalt pick-up on plate bottom
• The spraybar is fully protected from damage, easily positioned,with integral paving pad clamp points
• Optional compact wheelkit, easily fitted and removed
• Life lubricated vibration bearings

PCX 12/36 Petrol Honda GX120
Max power (Hp/kW) - 4.0 - 3.0
Plate size WxL (mm) - 360 X 606
Static pressure (kg/m2) - 586
Centrifugal force (kN) - 12.25
Travel speed (m/min) - 20
Vibration (m/sec2) - 4.74
Weight (kg) - 81

PCX 13/40 Petrol Honda GX120
Max power (Hp/kW) - 4.0 - 3.0
Plate size WxL (mm) - 400 X 606
Static pressure (kg/m2) - 520
Centrifugal force (kN) - 13
Travel speed (m/min) - 20
Vibration (m/sec2) - 3.2
Weight (kg) - 83.5
